Product Description
Anodized Aluminum Composite Materials is aluminum layer that has been treated to develop an exceptionally durable finish. To create anodized aluminum, you use an electrochemical process where the metal is immersed in a series of tanks, wherein one of the tanks, the anodic layer is grown from the metal itself.
|
Material |
Front side |
Aluminum Alloy Anodized |
|
Core |
Non-toxic polyethylene or Plastic fireproof materials(B1/A2) |
|
|
Back side |
Aluminium alloy sheet coated with polyester resin painting |
Because this anodized layer is created from the aluminum itself, rather than being painted on or applied, this anodized aluminum will never chip, flake, or peel, and it is much more durable than any other similar material on the market. Anodized aluminum is three times harder than the raw material, and 60 percent lighter than other competing metals like stainless steel and copper.
Specification
|
Panel Thickness |
2mm, 3mm, 4mm, 5mm, 6mm are available |
|
Alu thickness |
0.5mm, 0.4mm, 0.3mm, 0.21mm, 0.18mm,0.15mm, 0.12mm, 0.1mm, 0.06mm |
|
Width |
1220mm(regular),1250mm,1300mm,1500mm, 1550mm,1570mm,1575mm(Maximum) |
|
Length |
2440mm(regular), and or by customer's offers, 5800mm(Maximum) |
|
Standard size |
1220(Width)x2440(Length)x3mm(Thickness); 1250(Width)x2440(Length)x4mm(Thickness); |
|
Surface Finish |
MIRROR , MARBLE IMITATION, WOOD IMITATION, BRUSH, PVC FILM, PP FILM, PEARL SERIES,GLOSSY SURFACE, MATT SURFACE |
|
Core material |
( Normal non toxic polyethylene, one side unbroken polyethylene, two side unbroken polyethylene, virgin LDPE, ) B1 non-combustible mineral filled core, A2 non-combustible mineral filled core |
|
Coating |
PE COATING, PVDF COATING, FEVE COATING, ANODIZED COATING |
|
Standard |
According to China National Standard GB/t 17748-2016 |
What Are The Benefits of Anodized Aluminum Composite Materials?
Durability
The thick, porous layer formed on anodized aluminium serves as a barrier against corrosion, wear and tear and damages arising from heavy use, harsh environments or extreme climatic conditions. This makes the material highly durable and resistant.
01
Appearance
The anodising process enhances the natural texture of aluminium, giving it a beautiful and distinctive look that is not only decorative but also durable and long-lasting.
02
Custom Colour Options
The aluminium oxide layer can be dyed with a wide range of colours during anodizing. This possibility unlocks a spectrum of custom colour options for coil anodized aluminium, ranging from soft tones to rich hues and everything in between.
03
Lightweight
Due to the inherent properties of aluminium, anodized aluminium stays exceptionally lightweight even after anodising. This makes anodized aluminium a suitable option for applications where lightweight design is crucial without compromising integrity.
04
Cost
Another benefit of anodized aluminium is that when compared to other materials with similar durability and strength, anodized aluminium is relatively pocket-friendly.
05
