Description
Technical Parameters
Basic Panel Parameters of aluminum honeycomb panel fireproof
| Item | Specification |
|---|---|
| Total thickness | 8 / 10 / 12 / 15 / 20 mm (wall commonly 10‑15 mm) |
| Face & back skin | 0.6‑1.0 mm aluminum alloy |
| Honeycomb core | 3003 / 5052 aluminum core, cell size: 6‑12 mm |
| Standard dimension | 1220×2440 mm; max width ≤2000 mm, max length ≤10000 mm |
| Weight | 4.2‑7.0 kg/m² (depends on total thickness) |
| Alloy grade | 1100, 3003, 5052 |
| Edge treatment | Closed edge recommended for wall installation; open edge optional |
Mechanical Performance aluminum honeycomb panel fireproof
| Item | Specification |
|---|---|
| Bending stiffness | High rigidity, low deflection for wall cladding |
| Flatness | Excellent flatness, anti‑warping |
| Strength‑to‑weight ratio | High, light weight for wall mounting |
| Bonding strength | Compliant with international composite panel standards |
Surface & Finish Options aluminum honeycomb panel fireproof
| Item | Specification |
|---|---|
| Coating system | PVDF fluorocarbon (exterior wall), PE polyester, powder coating (interior wall) |
| Decorative finishes | Wood grain, stone grain, brushed metal, anodizing, solid color |
| Color | Custom per RAL / Pantone color codes |
| Special option | Perforated acoustic honeycomb wall panel available |
